PC817X2J000F
RoHS
/
Package 4-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
OPTOISOLATOR 5KV TRANS 4DIP
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1118
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 6.5mm
Technical
Current Transfer Ratio (Max) 230% @ 5mA
Input Current 20mA
Current Transfer Ratio (Min) 130% @ 5mA
Collector Emitter Saturation Voltage 200mV
Max Input Current 50mA
Reverse Breakdown Voltage 6V
Rise / Fall Time (Typ) 4μs 3μs
Max Collector Current 50mA
Collector Emitter Voltage (VCEO) 80V
Fall Time (Typ) 18 μs
Rise Time 18μs
Output Current per Channel 50mA
Forward Current 50mA
Input Type DC
Voltage - Forward (Vf) (Typ) 1.2V
Power Dissipation 200mW
Number of Channels 1
Configuration SINGLE
Number of Elements 1
Output Type Transistor
Output Voltage 80V
Voltage - Isolation 5000Vrms
Max Power Dissipation 200mW
Additional Feature UL RECOGNIZED
Terminal Finish Tin/Bismuth (Sn/Bi)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e6
Published 2003
Packaging Tube
Operating Temperature -30°C~100°C
Physical
Number of Pins 4
Package / Case 4-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
