PC4H510NIP
RoHS
/
Package 4-SOIC (0.209, 5.30mm Width)
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
OPTOISOLATOR 2.5KV TRANS 4SMD
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.42085
≥1 USD $0.42085
≥10 USD $0.34485
≥100 USD $0.3344
≥500 USD $0.32395
≥1000 USD $0.31255
Inventory: 1096
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SOIC (0.209, 5.30mm Width)
Technical
Operating Temperature -25°C~100°C
Packaging Tape & Reel (TR)
Published 2003
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Additional Feature UL RECOGNIZED
Reach Compliance Code unknown
Voltage - Isolation 2500Vrms
Output Voltage 350V
Output Type Transistor
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.2V
Input Type DC
Output Current per Channel 50mA
Collector Emitter Voltage (VCEO) 300mV
Rise / Fall Time (Typ) 4μs 5μs
Current - Output / Channel 50mA
Forward Current-Max 0.05A
Current Transfer Ratio (Min) 40% @ 5mA
Current Transfer Ratio (Max) 240% @ 5mA
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
