PC457S0NIP0F
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
OPTOISOLATOR 3.75KV TRANS 8SO
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 7006
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -55°C~100°C
Packaging Cut Tape (CT)
Published 2006
Series OPIC?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Additional Feature UL RECOGNIZED
Max Power Dissipation 100mW
Reach Compliance Code unknown
Voltage - Isolation 3750Vrms
Output Voltage 20V
Output Type Transistor
Number of Elements 1
Configuration SINGLE
Power Dissipation 100mW
Output Current 8mA
Voltage - Forward (Vf) (Typ) 1.5V
Input Type DC
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Forward Current 25mA
Data Rate 1 MBps
Output Current per Channel 8mA
Max Collector Current 8mA
Reverse Breakdown Voltage 5V
Max Input Current 25mA
Current Transfer Ratio (Min) 19% @ 16mA
Input Current 25mA
Current Transfer Ratio (Max) 50% @ 16mA
Turn On / Turn Off Time (Typ) 200ns, 300ns
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
