PC3Q64Q5J00F
RoHS
/
Package 16-SOIC (0.173, 4.40mm Width)
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
OPTOISO 2.5KV 4CH TRANS 16SOIC
PDF
/
Buying Options
Total Price: USD $18.85
Unit Price: USD $18.8499
≥1 USD $18.8499
≥10 USD $15.46695
≥100 USD $14.9834
≥500 USD $14.5008
≥1000 USD $14.01725
Inventory: 1124
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Vce Saturation (Max) 200mV
Current Transfer Ratio (Max) 400% @ 1mA
Current Transfer Ratio (Min) 20% @ 1mA
Current - DC Forward (If) (Max) 50mA
Collector Emitter Saturation Voltage 200mV
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Rise / Fall Time (Typ) 4μs 3μs
Max Collector Current 50mA
Collector Emitter Voltage (VCEO) 80V
Fall Time (Typ) 18 μs
Forward Voltage 1.4V
Rise Time 18μs
Output Current per Channel 50mA
Forward Current 50mA
Input Type AC, DC
Voltage - Forward (Vf) (Typ) 1.2V
Power Dissipation 170mW
Number of Circuits 4
Number of Channels 4
Number of Elements 4
Output Type Transistor
Output Voltage 80V
Voltage - Isolation 2500Vrms
Max Power Dissipation 170mW
Min Operating Temperature -30°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -30°C~100°C
Physical
Supplier Device Package 16-Mini-Flat
Number of Pins 16
Package / Case 16-SOIC (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
