PC357M0J000F
RoHS
/
Package 4-Miniflat
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
Optocoupler DC-IN 1-CH Transistor DC-OUT 4-Pin Mini-Flat T/R
PDF
/
Inventory: 6416
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Current Transfer Ratio (Max) 600% @ 5mA
Current Transfer Ratio (Min) 80% @ 5mA
Collector Emitter Saturation Voltage 200mV
Max Input Current 50mA
Rise / Fall Time (Typ) 4μs 3μs
Max Collector Current 50mA
Collector Emitter Voltage (VCEO) 80V
Output Current per Channel 50mA
Max Output Voltage 80V
Input Type DC
Voltage - Forward (Vf) (Typ) 1.2V
Number of Channels 1
Output Type Transistor
Voltage - Isolation 3750Vrms
Max Power Dissipation 170mW
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -30°C~100°C
Physical
Number of Pins 4
Package / Case 4-Miniflat
Mounting Type Surface Mount
Mount Surface Mount
