EL213(TA)-V
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Optoisolators - Transistor, Photovoltaic Output
Description
8-SOIC (0.154 3.90mm Width) 1 DC Active Optoisolator Transistor Output 100% @ 10mA 3750Vrms 60mA -55C~110C
PDF
/
Inventory: 8687
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -55°C~110°C
Packaging Tape & Reel (TR)
Published 2010
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 240mW
Voltage - Isolation 3750Vrms
Output Voltage 80V
Output Type Transistor with Base
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.3V
Input Type DC
Optoelectronic Device Type TRANSISTOR OUTPUT OPTOCOUPLER
Collector Emitter Voltage (VCEO) 400mV
Rise / Fall Time (Typ) 1.6μs 2.2μs
Max Input Current 60mA
Collector Emitter Saturation Voltage 400mV
Current Transfer Ratio (Min) 100% @ 10mA
Turn On / Turn Off Time (Typ) 3μs, 3μs
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
