RoHS
/
Package Nonstandard, 5 Lead
Category Isolators / Optoisolators - Logic Output
Description Nonstandard 5Lead 1 1/0 DC Logic Output Optoisolator 5mus 5mus (Typ) 20mA -20C~75C 5mus
PDF
/
Inventory: 7571
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Inputs - Side 1/Side 2 1/0
Isolation Voltage 10kV
Propagation Delay tpLH / tpHL (Max) 5μs, 5μs (Typ)
Input Current 20mA
Rise / Fall Time (Typ) 25ns 25ns
Forward Voltage 2.3V
Input Type DC
Propagation Delay 5 μs
Voltage - Forward (Vf) (Typ) 2.3V Max
Number of Channels 1
Output Type Push-Pull, Totem Pole
Output Voltage 30V
Voltage - Supply 4.5V~16V
Min Operating Temperature -20°C
Max Operating Temperature 75°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2007
Packaging Bulk
Operating Temperature -20°C~75°C

Physical

Number of Pins 5
Package / Case Nonstandard, 5 Lead
Mounting Type Through Hole
Mount Through Hole
