PC400J00000F
RoHS
RoHS compliant
RoHS compliantPackage 6-SOIC (0.173, 4.40mm Width), 5 Leads
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 3.75KV OPEN COLL 5MFP
PDF
/
Buying Options
Total Price: USD $2.66
Unit Price: USD $2.6576
≥1 USD $2.6576
≥10 USD $1.77056
≥100 USD $1.362328
≥500 USD $1.231525
≥1000 USD $1.058341
Inventory: 18058
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 3mm
Technical
Hysteresis Ratio-Nom 0.7
Inputs - Side 1/Side 2 1/0
Propagation Delay tpLH / tpHL (Max) 6μs, 3μs
Reverse Breakdown Voltage 6V
Rise / Fall Time (Typ) 100ns 50ns
Turn-Off Delay Time 1 μs
Fall Time (Typ) 500 ns
Rise Time 500ns
Output Current per Channel 50mA
Direction Unidirectional
Forward Current 50mA
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Turn On Delay Time 2 μs
Input Type DC
Propagation Delay 6 μs
Voltage - Forward (Vf) (Typ) 1.1V
Power Dissipation 70mW
Number of Channels 1
Configuration COMPLEX
Number of Elements 1
Output Type Open Collector
Voltage - Isolation 3750Vrms
Voltage - Supply 3V~15V
Max Power Dissipation 150mW
Additional Feature WITH SIGNAL PROCESSING CIRCUIT, UL RECOGNIZED, TTL COMPATIBLE
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e2
Series OPIC?
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Number of Pins 5
Package / Case 6-SOIC (0.173, 4.40mm Width), 5 Leads
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Tin
Supply Chain
Factory Lead Time 16 Weeks
