PC910L0YSZ0F
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 5KV OPEN COLL 8DIP
PDF
/
Inventory: 3355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 10kV/μs
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Reverse Breakdown Voltage 5V
Current - Output / Channel 50mA
Rise / Fall Time (Typ) 10ns 20ns
Fall Time (Typ) 20 ns
Rise Time 10ns
Output Current per Channel 10mA
Direction Unidirectional
Data Rate 10Mbps
Forward Current 20mA
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Turn On Delay Time 75 ns
Input Type DC
Propagation Delay 75 ns
Voltage - Forward (Vf) (Typ) 1.6V
Power Dissipation 85mW
Configuration COMPLEX
Number of Elements 1
Output Type Open Collector
Voltage - Isolation 5000Vrms
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 85mW
Additional Feature UL RECOGNIZED, VDE APPROVED, TTL COMPATIBLE
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Series OPIC?
Published 1998
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
