PC900V0NIPXF
RoHS
/
Package 6-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 5KV OPEN COLLECTOR 6SMD
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 15515
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Hysteresis Ratio-Nom 0.7
Reverse Voltage (DC) 6V
Inputs - Side 1/Side 2 1/0
Propagation Delay tpLH / tpHL (Max) 6μs, 3μs
Reverse Breakdown Voltage 6V
Rise / Fall Time (Typ) 100ns 50ns
Max Collector Current 50mA
Fall Time (Typ) 500 ns
Rise Time 500ns
Output Current per Channel 50mA
Direction Unidirectional
Max Output Voltage 16V
Forward Current 50mA
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Turn On Delay Time 6 μs
Input Type DC
Propagation Delay 6 μs
Voltage - Forward (Vf) (Typ) 1.1V
Output Current 50mA
Power Dissipation 170mW
Number of Channels 1
Configuration COMPLEX
Number of Elements 1
Output Type Open Collector
Voltage - Isolation 5000Vrms
Voltage - Supply 3V~15V
Max Power Dissipation 170mW
Additional Feature UL RECOGNIZED, TTL COMPATIBLE
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Series OPIC?
Published 2005
Packaging Cut Tape (CT)
Operating Temperature -25°C~85°C
Physical
Number of Pins 6
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
