HCPL0638
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Optoisolators - Logic Output
Description
8-SOIC (0.154 3.90mm Width) 2 2/0 DC Logic Output Optoisolator 10kV/mus 3750Vrms 10Mbps 50mA
PDF
/
Buying Options
Total Price: USD $3.46
Unit Price: USD $3.4584
≥1 USD $3.4584
≥10 USD $2.44552
≥100 USD $2.002968
≥500 USD $1.688526
≥1000 USD $1.548791
≥3000 USD $1.484745
Inventory: 107
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Reverse Voltage (DC) 5V
Inputs - Side 1/Side 2 2/0
Common Mode Transient Immunity (Min) 10kV/μs
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
On-State Current-Max 0.015A
Input Current 15mA
Max Input Current 50mA
Reverse Breakdown Voltage 5V
Rise / Fall Time (Typ) 17ns 5ns
Fall Time (Typ) 75 ns
Rise Time 75ns
Output Current per Channel 15mA
Direction Unidirectional
Data Rate 10Mbps
Response Time 1e-7 ns
Forward Current 50mA
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Turn On Delay Time 75 ns
Input Type DC
Propagation Delay 75 ns
Voltage - Forward (Vf) (Typ) 1.75V Max
Output Current 15mA
Power Dissipation 85mW
Number of Channels 2
Number of Elements 2
Output Type Open Collector, Schottky Clamped
Output Voltage 7V
Voltage - Isolation 3750Vrms
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 85mW
Subcategory Optocoupler - IC Outputs
Additional Feature CMOS COMPATIBLE, UL RECOGNIZED
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 252mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 5 Weeks
