HCPL0600R1
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Optoisolators - Logic Output
Description
8-SOIC (0.154 3.90mm Width) 1 1/0 DC Logic Output Optoisolator 5kV/mus 3750Vrms 10Mbps 50mA
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.064
≥1 USD $1.064
≥10 USD $0.87305
≥100 USD $0.8455
≥500 USD $0.81795
≥1000 USD $0.79135
Inventory: 26270
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 85mW
Voltage - Supply 4.5V~5.5V
Voltage - Isolation 3750Vrms
Output Type Open Collector
Max Output Current 50mA
Number of Channels 1
Power Dissipation 85mW
Output Current 50mA
Voltage - Forward (Vf) (Typ) 1.75V Max
Propagation Delay 75 ns
Input Type DC
Forward Current 50mA
Data Rate 10Mbps
Output Current per Channel 50mA
Rise Time 50ns
Fall Time (Typ) 12 ns
Rise / Fall Time (Typ) 50ns 12ns
Reverse Breakdown Voltage 5V
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Common Mode Transient Immunity (Min) 5kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
