H11N2SR2VM
RoHS
/
Package 6-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
Optocoupler Logic-Out Open Collector DC-IN 1-CH 6-Pin PDIP SMD White T/R
PDF
/
Inventory: 3253
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Published 2014
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Optocoupler - IC Outputs
Max Power Dissipation 250mW
Voltage - Supply 4V~15V
Supply Voltage 15V
Voltage - Isolation 4170Vrms
Output Type Open Collector
Max Output Current 50mA
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Power Dissipation 250mW
Output Current 50mA
Voltage - Forward (Vf) (Typ) 1.4V
Propagation Delay 330 ns
Input Type DC
Turn On Delay Time 330 ns
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Forward Current 30mA
Response Time 1.5e-7 ns
Data Rate 5MHz
Direction Unidirectional
Output Current per Channel 50mA
Rise Time 7.5ns
Fall Time (Typ) 12 ns
Rise / Fall Time (Typ) 7.5ns 12ns
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Reverse Breakdown Voltage 6V
On-State Current-Max 0.05A
Propagation Delay tpLH / tpHL (Max) 330ns, 330ns
Inputs - Side 1/Side 2 1/0
Hysteresis Ratio-Nom 0.65
Physical
Weight 810mg
Number of Pins 6
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
