H11L3VM
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 4.17KV OPN COLL 6DIP
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $0.90992
≥100 USD $0.673376
≥500 USD $0.618746
≥1000 USD $0.509546
≥3000 USD $0.48407
Inventory: 269
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP (0.300, 7.62mm)
Number of Pins 6
Weight 855mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature UL RECOGNIZED, VDE APPROVED
Subcategory Optocoupler - IC Outputs
Max Power Dissipation 250mW
Voltage - Supply 3V~15V
Supply Voltage 16V
Voltage - Isolation 4170Vrms
Output Type Open Collector
Max Output Current 50mA
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Power Dissipation 250mW
Output Current 50mA
Voltage - Forward (Vf) (Typ) 1.2V
Propagation Delay 4 μs
Input Type DC
Turn On Delay Time 4 μs
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Forward Current 60mA
Data Rate 1MHz
Direction Unidirectional
Output Current per Channel 50mA
Rise Time 100 ns
Fall Time (Typ) 100 ns
Rise / Fall Time (Typ) 100ns, 100ns
Reverse Breakdown Voltage 6V
Current - DC Forward (If) (Max) 30mA
On-State Current-Max 0.05A
Propagation Delay tpLH / tpHL (Max) 4μs, 4μs
Inputs - Side 1/Side 2 1/0
Reverse Voltage (DC) 6V
Hysteresis Ratio-Nom 0.75
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
