H11L3FR2VM

ON Semiconductor
RoHS
/
Package 6-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description Logic Output Optocouplers 6-Pin DIP Schmitt Trigger Output Optocoupler
PDF
/
Inventory: 9465
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 3V~15V
Voltage - Isolation 4170Vrms
Output Type Open Collector
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.2V
Input Type DC
Data Rate 1MHz
Rise / Fall Time (Typ) 100ns 100ns
Current - Output / Channel 50mA
Current - DC Forward (If) (Max) 30mA
Propagation Delay tpLH / tpHL (Max) 4μs, 4μs
Inputs - Side 1/Side 2 1/0
