74OL6011SD
RoHS
/
Package 6-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
6-SMD Gull Wing 1 1/0 Logic Logic Output Optoisolator 5kV/mus 5300Vrms 15MBd 40mA
PDF
/
Inventory: 7371
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 5kV/μs
Propagation Delay tpLH / tpHL (Max) 180ns, 120ns
Current - Output / Channel 40mA
Rise / Fall Time (Typ) 50ns 5ns
Data Rate 15MBd
Input Type Logic
Number of Channels 1
Output Type Open Collector, Schottky Clamped
Voltage - Isolation 5300Vrms
Voltage - Supply 4.5V~15V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series OPTOLOGIC?
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Supplier Device Package 6-SMD
Package / Case 6-SMD, Gull Wing
Mounting Type Surface Mount
