74OL6001W
RoHS
/
Package 6-DIP (0.400, 10.16mm)
Category Isolators / Optoisolators - Logic Output
Description
6-DIP (0.400 10.16mm) 1 1/0 Logic Logic Output Optoisolator 5kV/mus 5300Vrms 15MBd 40mA
PDF
/
Inventory: 6257
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 5kV/μs
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Current - Output / Channel 40mA
Rise / Fall Time (Typ) 45ns 5ns
Data Rate 15MBd
Input Type Logic
Number of Channels 1
Output Type Push-Pull, Totem Pole
Voltage - Isolation 5300Vrms
Voltage - Supply 4.5V~5.5V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series OPTOLOGIC?
Published 2003
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Supplier Device Package 6-DIP
Package / Case 6-DIP (0.400, 10.16mm)
Mounting Type Through Hole
