H11L3S(TB)-V
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
6-SMD Gull Wing 1 1/0 DC Logic Output Optoisolator 4mus 4mus 5000Vrms 1MHz 60mA
PDF
/
Inventory: 9459
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, Gull Wing
Number of Pins 6
Technical
Operating Temperature -55°C~100°C
Packaging Tape & Reel (TR)
Published 2014
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 250mW
Voltage - Supply 3V~16V
Voltage - Isolation 5000Vrms
Output Type Open Collector
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.15V
Propagation Delay 4 μs
Input Type DC
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Data Rate 1MHz
Direction Unidirectional
Output Current per Channel 50mA
Fall Time (Typ) 100 ns
Rise / Fall Time (Typ) 100ns 100ns
Current - DC Forward (If) (Max) 60mA
Propagation Delay tpLH / tpHL (Max) 4μs, 4μs
Inputs - Side 1/Side 2 1/0
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
