EL2601S1(TA)
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 5KV OPEN COLLECTOR 8SMD
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.654254
≥1 USD $1.654254
≥200 USD $0.660389
≥500 USD $0.638069
≥1000 USD $0.627566
Inventory: 6133
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing
Shape RECTANGULAR
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2013
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Additional Feature CMOS COMPATIBLE, UL APPROVED
Packing Method TR
Voltage - Supply 7V
Number of Functions 1
Voltage - Isolation 5000Vrms
Output Type Open Collector
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.4V
Propagation Delay 75 ns
Input Type DC
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Response Time 4e-8 ns
Data Rate 10Mbps
Output Current per Channel 50mA
Rise / Fall Time (Typ) 40ns 10ns
Forward Current-Max 0.05A
On-State Current-Max 0.05A
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Common Mode Transient Immunity (Min) 5kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
RoHS Status ROHS3 Compliant
