6N137-V
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Logic Output
Description
8-DIP (0.300 7.62mm) 1 1/0 DC Logic Output Optoisolator 5kV/mus 5000Vrms 10Mbps 50mA
PDF
/
Buying Options
Total Price: USD $1.87
Unit Price: USD $1.873508
≥1 USD $1.873508
≥180 USD $0.748353
≥495 USD $0.723408
≥990 USD $0.710279
Inventory: 1501
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 5kV/μs
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
On-State Current-Max 0.05A
Rise / Fall Time (Typ) 40ns 10ns
Fall Time (Typ) 75 ns
Rise Time 75ns
Output Current per Channel 50mA
Direction Unidirectional
Data Rate 10Mbps
Response Time 4e-8 ns
Forward Current 50mA
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Turn On Delay Time 75 ns
Input Type DC
Propagation Delay 75 ns
Voltage - Forward (Vf) (Typ) 1.4V
Number of Channels 1
Configuration SINGLE
Number of Elements 1
Output Type Open Collector
Voltage - Isolation 5000Vrms
Number of Functions 1
Voltage - Supply 7V
Max Power Dissipation 100mW
Additional Feature CMOS COMPATIBLE, UL APPROVED, VDE APPROVED
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2009
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Shape RECTANGULAR
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
