PS9687L2-E3-A
RoHS
/
Package 8-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 5KV OPEN COLL 8SMD GW
PDF
/
Inventory: 5464
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing
Number of Pins 8
Supplier Device Package 8-DIP Gull Wing
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series NEPOC
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 4.5V~5.5V
Voltage - Isolation 5000Vrms
Output Type Open Collector
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.65V
Propagation Delay 40 ns
Input Type DC
Data Rate 10Mbps
Output Current per Channel 25mA
Rise / Fall Time (Typ) 20ns 10ns
Current - Output / Channel 25mA
Current - DC Forward (If) (Max) 30mA
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Common Mode Transient Immunity (Min) 10kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
RoHS Status RoHS Compliant
