PS9324L2-E3-AX
RoHS
RoHS compliant
RoHS compliantPackage 6-SOIC (0.268, 6.80mm Width)
Category Isolators / Optoisolators - Logic Output
Description
6-SOIC (0.268 6.80mm Width) 1 1/0 DC Logic Output Optoisolator 15kV/mus 5000Vrms 10Mbps 25mA
PDF
/
Buying Options
Total Price: USD $4.51
Unit Price: USD $4.5144
≥1 USD $4.5144
≥10 USD $3.19176
≥100 USD $2.614128
≥500 USD $2.203784
≥1000 USD $2.021395
Inventory: 2036
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SOIC (0.268, 6.80mm Width)
Number of Pins 6
Technical
Operating Temperature -40°C~110°C
Packaging Tape & Reel (TR)
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Power Dissipation 200mW
Voltage - Supply 2.7V~5.5V
Voltage - Isolation 5000Vrms
Output Type Open Collector
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.55V
Propagation Delay 75 ns
Input Type DC
Data Rate 10Mbps
Direction Unidirectional
Output Current per Channel 25mA
Fall Time (Typ) 5 ns
Rise / Fall Time (Typ) 20ns 5ns
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
