PS9317L2-AX
RoHS
RoHS compliant
RoHS compliantPackage 6-SOIC (0.268, 6.80mm Width)
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 5KV OPEN COLL 6DIP GW
PDF
/
Buying Options
Total Price: USD $10.87
Unit Price: USD $10.872125
≥1 USD $10.872125
≥200 USD $4.339135
≥500 USD $4.193403
≥1000 USD $4.122506
Inventory: 1637
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SOIC (0.268, 6.80mm Width)
Number of Pins 6
Supplier Device Package 6-SDIP Gull Wing
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series NEPOC
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 40mW
Voltage - Supply 4.5V~5.5V
Voltage - Isolation 5000Vrms
Output Type Open Collector
Max Output Current 25mA
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.56V
Propagation Delay 75 ns
Input Type DC
Forward Current 12mA
Data Rate 10Mbps
Direction Unidirectional
Output Current per Channel 25mA
Forward Voltage 1.56V
Fall Time (Typ) 5 ns
Rise / Fall Time (Typ) 20ns 5ns
Current - Output / Channel 25mA
Current - DC Forward (If) (Max) 30mA
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
