PS9213-A
RoHS
/
Package 6-SOIC (0.173, 4.40mm Width), 5 Leads
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 2.5KV OPN COLLECTOR 5SOP
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.42275
≥1 USD $0.42275
≥10 USD $0.34675
≥100 USD $0.3363
≥500 USD $0.32585
≥1000 USD $0.31445
Inventory: 8176
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SOIC (0.173, 4.40mm Width), 5 Leads
Number of Pins 5
Supplier Device Package 5-SO
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Series NEPOC
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Supply 4.5V~30V
Voltage - Isolation 2500Vrms
Output Type Open Collector
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.65V
Propagation Delay 250 ns
Input Type DC
Data Rate 1Mbps
Output Current per Channel 15mA
Current - Output / Channel 15mA
Current - DC Forward (If) (Max) 25mA
Propagation Delay tpLH / tpHL (Max) 750ns, 500ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
RoHS Status RoHS Compliant
