PS9121-AX
RoHS
RoHS compliant
RoHS compliantPackage 6-SOIC (0.173, 4.40mm Width), 5 Leads
Category Isolators / Optoisolators - Logic Output
Description
6-SOIC (0.173 4.40mm Width) 5Leads 1 1/0 DC Logic Output Optoisolator 15kV/mus 3750Vrms 15Mbps 30mA
PDF
/
Buying Options
Total Price: USD $3.63
Unit Price: USD $3.6344
≥1 USD $3.6344
≥10 USD $2.5718
≥100 USD $2.156
Inventory: 583
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SOIC (0.173, 4.40mm Width), 5 Leads
Number of Pins 5
Supplier Device Package 5-SO
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series NEPOC
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 40mW
Voltage - Supply 2.7V~3.6V
Voltage - Isolation 3750Vrms
Output Type Open Collector
Max Output Current 25mA
Number of Elements 1
Number of Channels 1
Power Dissipation 40mW
Output Current 25mA
Voltage - Forward (Vf) (Typ) 1.65V
Propagation Delay 75 ns
Input Type DC
Turn On Delay Time 75 ns
Forward Current 12.5mA
Max Output Voltage 7V
Data Rate 15Mbps
Direction Unidirectional
Output Current per Channel 25mA
Forward Voltage 1.65V
Fall Time (Typ) 5 ns
Rise / Fall Time (Typ) 20ns 5ns
Current - Output / Channel 25mA
Reverse Breakdown Voltage 5V
Current - DC Forward (If) (Max) 30mA
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
