HCPL-7720-500E
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, Gull Wing
Category Isolators / Optoisolators - Logic Output
Description
Optocoupler Logic-Out Push-Pull Logic, Buffer-IN 1-CH 8-Pin PDIP SMD T/R
PDF
/
Buying Options
Total Price: USD $6.24
Unit Price: USD $6.2392
≥1 USD $6.2392
≥10 USD $4.41144
≥100 USD $3.613016
≥500 USD $3.045856
Inventory: 5377
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 10kV/μs
Propagation Delay tpLH / tpHL (Max) 40ns, 40ns
Rise / Fall Time (Typ) 9ns 8ns
Fall Time (Typ) 8 ns
Rise Time 9ns
Output Current per Channel 10mA
Direction Unidirectional
Data Rate 25MBd
Response Time 4e-8 ns
Turn On Delay Time 40 ns
Input Type Logic
Propagation Delay 40 ns
Output Current 10mA
Power Dissipation 150mW
Number of Channels 1
Configuration COMPLEX
Number of Elements 1
Max Output Current 10mA
Output Type Push-Pull, Totem Pole
Output Voltage 5V
Voltage - Isolation 3750Vrms
Supply Voltage 5.5V
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 150mW
Subcategory Optocoupler - IC Outputs
Additional Feature UL RECOGNIZED, VDE APPROVED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SMD, Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
