HCPL-5200#200
RoHS
/
Package 8-CDIP (0.300, 7.62mm)
Category Isolators / Optoisolators - Logic Output
Description
8-CDIP (0.300 7.62mm) 1 1/0 DC Logic Output Optoisolator 1kV/mus 1500VDC 5MBd 8mA
PDF
/
Buying Options
Total Price: USD $217.55
Unit Price: USD $217.554095
≥1 USD $217.554095
≥200 USD $86.806322
≥500 USD $83.904813
≥1000 USD $82.472439
Inventory: 1403
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount, Through Hole
Mounting Type Through Hole
Package / Case 8-CDIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature CMOS COMPATIBLE, HIGH RELIABILITY
Subcategory Optocoupler - IC Outputs
Max Power Dissipation 200mW
Voltage - Supply 4.5V~20V
Supply Voltage 5V
Voltage - Isolation 1500VDC
Output Type Tri-State
Max Output Current 15mA
Number of Elements 1
Configuration COMPLEX
Number of Channels 1
Power Dissipation 200mW
Output Current 15mA
Voltage - Forward (Vf) (Typ) 1.3V
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 1kV/μs
Propagation Delay tpLH / tpHL (Max) 350ns, 350ns
Reverse Breakdown Voltage 3V
Rise / Fall Time (Typ) 45ns 10ns
Fall Time (Typ) 10 ns
Rise Time 45ns
Output Current per Channel 15mA
Direction Unidirectional
Data Rate 5MBd
Response Time 4.5e-8 ns
Forward Current 8mA
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Turn On Delay Time 350 ns
Input Type DC
Propagation Delay 350 ns
Compliance
Lead Free Exempt
RoHS Status Non-RoHS Compliant
Radiation Hardening Yes
