ACPL-W456-520E
RoHS
RoHS compliant
RoHS compliantPackage 6-SOIC (0.295, 7.50mm Width)
Category Isolators / Optoisolators - Logic Output
Description
Logic Output Optocouplers 1MBd 3750Vrms
PDF
/
Inventory: 3805
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 6-SOIC (0.295, 7.50mm Width)
Technical
Operating Temperature -40°C~100°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature UL RECOGNIZED
Voltage - Supply 4.5V~30V
Reach Compliance Code compliant
Voltage - Isolation 5000Vrms
Output Type Open Collector, Schottky Clamped
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.5V
Input Type DC
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Current - Output / Channel 15mA
Forward Current-Max 0.025A
Current - DC Forward (If) (Max) 25mA
Propagation Delay tpLH / tpHL (Max) 550ns, 400ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 1/0
Compliance
RoHS Status RoHS Compliant
