ACPL-W456-020E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 6-SOIC (0.295, 7.50mm Width)
Category Isolators / Optoisolators - Logic Output
Description Logic Output Optocouplers 1MBd 3750Vrms
PDF
/
Inventory: 9605
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 15kV/μs
Propagation Delay tpLH / tpHL (Max) 550ns, 400ns
Current - DC Forward (If) (Max) 25mA
Current - Output / Channel 15mA
Input Type DC
Voltage - Forward (Vf) (Typ) 1.5V
Number of Channels 1
Output Type Open Collector, Schottky Clamped
Voltage - Isolation 5000Vrms
Reach Compliance Code compliant
Voltage - Supply 4.5V~30V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2010
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 6-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
