ACPL-061L-060E
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 3.75KV TRI-STATE 8SO
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $1.72216
≥100 USD $1.32528
≥500 USD $1.197962
≥1000 USD $1.029494
≥3000 USD $0.973342
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Reverse Voltage (DC) 5V
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 20kV/μs
Propagation Delay tpLH / tpHL (Max) 80ns, 80ns
Current - DC Forward (If) (Max) 8mA
Reverse Breakdown Voltage 5V
Rise / Fall Time (Typ) 12ns 12ns
Fall Time (Typ) 12 ns
Rise Time 12ns
Output Current per Channel 10mA
Direction Unidirectional
Data Rate 10MBd
Forward Current 2mA
Turn On Delay Time 80 ns
Input Type DC
Propagation Delay 80 ns
Voltage - Forward (Vf) (Typ) 1.3V
Output Current 10mA
Power Dissipation 20mW
Number of Channels 1
Output Type Tri-State
Voltage - Isolation 3750Vrms
Voltage - Supply 2.7V~5.5V
Max Power Dissipation 20mW
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
