5962-9800102KYA
RoHS
/
Package 8-SMD Butt Joint
Category Isolators / Optoisolators - Logic Output
Description
8-SMD Butt Joint 2 2/0 DC Logic Output Optoisolator 1kV/mus 1500VDC 10MBd 20mA
PDF
/
Buying Options
Total Price: USD $1256.27
Unit Price: USD $1256.269371
≥1 USD $1256.269371
≥200 USD $501.259968
≥500 USD $484.50999
≥1000 USD $476.233469
Inventory: 7484
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Hysteresis Ratio-Nom 0.0125
Inputs - Side 1/Side 2 2/0
Common Mode Transient Immunity (Min) 1kV/μs
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Current - DC Forward (If) (Max) 20mA
Rise / Fall Time (Typ) 35ns 35ns
Fall Time (Typ) 40 ns
Rise Time 90ns
Output Current per Channel 25mA
Data Rate 10MBd
Response Time 1.4e-7 ns
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Input Type DC
Propagation Delay 100 ns
Voltage - Forward (Vf) (Typ) 1.5V
Number of Channels 2
Number of Elements 2
Max Output Current 25mA
Output Type Open Collector, Schottky Clamped
Voltage - Isolation 1500VDC
Supply Voltage 5.5V
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 200mW
Subcategory Optocoupler - IC Outputs
HTS Code 8541.40.80.00
Additional Feature OPEN COLLECTOR, TTL COMPATIBLE, HIGH RELIABILITY
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Package / Case 8-SMD Butt Joint
Mounting Type Surface Mount
Mount Surface Mount, Through Hole
Supply Chain
Factory Lead Time 56 Weeks
