EE-SPY415
RoHS
RoHS compliant
RoHS compliantPackage Module, Connector
Category Sensors, Transducers / Optical Sensors - Reflective - Logic Output
Description
OMRON ELECTRONIC COMPONENTS EE-SPY415 OPTICAL SENSOR (SWITCH) REFLECTIVE
PDF
/
Inventory: 5441
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case Module, Connector
Number of Pins 3
Technical
Packaging Bulk
Published 1999
Feature Improved Response Time
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Max Operating Temperature 60°C
Min Operating Temperature -10°C
Max Power Dissipation 250mW
Voltage - Supply 10.8V~13.2V
Output Voltage 12V
Output Type DIGITAL VOLTAGE
Operating Supply Voltage 7V
Number of Channels 1
Operating Supply Current 25mA
Output Configuration NPN - Open Collector/Dark-ON
Output Current 20mA
Rise Time 1ms
Fall Time (Typ) 1 ms
Collector Emitter Voltage (VCEO) 16V
Max Collector Current 30mA
Sensing Distance 0.433 (11mm)
Sensing Method Reflective
Low Level Output Current 20mA
Sensors/Transducers Type LINEAR POSITION SENSOR,PHOTOELECTRIC,DIFFUSE
Input Current 25mA
Output Range 0.40-0.90V
Sensing Object Black Paper, OHP Paper
Dimensions
Height 11mm
Length 33mm
Width 9.6mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
