RPR-359F
RoHS
RoHS compliant
RoHS compliantPackage PCB Mount
Category Sensors, Transducers / Optical Sensors - Reflective - Analog Output
Description
PHOTOINTERRUPTR REFL 3.5MM 800NM
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9291
≥1 USD $0.9291
≥10 USD $0.76285
≥100 USD $0.7391
≥500 USD $0.71535
≥1000 USD $0.6916
Inventory: 31716
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 5.8mm
Technical
Gap Size 3.5mm
Measurement Range-Min 3.5 mm
Measurement Range-Max 3.5 mm
Reverse Voltage (DC) 5V
Housing PLASTIC
Sensors/Transducers Type LINEAR POSITION SENSOR,PHOTOELECTRIC,DIFFUSE
Sensing Method Reflective
Wavelength 800 nm
Collector Emitter Breakdown Voltage 30V
Sensing Distance 0.138 (3.5mm)
Max Collector Current 30mA
Collector Emitter Voltage (VCEO) 30V
Fall Time (Typ) 10 μs
Forward Voltage 1.3V
Rise Time 10μs
Output Current-Max 0.5mA
Response Time 10μs, 10μs
Forward Current 50mA
Termination Type SOLDER
Number of Channels 1
Output Type Phototransistor
Body Length or Diameter 8.7mm
Subcategory Position, Linear, Photoelectric Sensors
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e2
Published 2002
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
Number of Pins 4
Package / Case PCB Mount
Mounting Type Through Hole
Mount Through Hole
