QRD1313
RoHS
/
Package Radial - 4 Leads
Category Sensors, Transducers / Optical Sensors - Reflective - Analog Output
Description
Bulk Photodarlington 1 Reflective Reflective Optical Sensor 0.050 (1.27mm) 50mA 15V -40C~85C
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
Inventory: 1157
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Current - DC Forward (If) (Max) 50mA
Sensing Method Reflective
Wavelength 940 nm
Reverse Voltage 5V
Reverse Breakdown Voltage 5V
Collector Emitter Breakdown Voltage 15V
Sensing Distance 0.050 (1.27mm)
Max Collector Current 10mA
Collector Emitter Voltage (VCEO) 15V
Forward Voltage 1.7V
Forward Current 20mA
Power Dissipation 100mW
Number of Channels 1
Operating Supply Voltage 1.7V
Output Type Photodarlington
Output Voltage 15V
Voltage - Rated DC 30V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2009
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Number of Pins 4
Package / Case Radial - 4 Leads
Mounting Type Through Hole
Mount Through Hole
