EE-SY191
RoHS
/
Package PCB Mount
Category Sensors, Transducers / Optical Sensors - Reflective - Analog Output
Description
OPTO SENSOR HORZ REFLECT TYPE
PDF
/
Inventory: 3082
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case PCB Mount
Number of Pins 4
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 1999
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Additional Feature 2NA DARK CURRENT
Reach Compliance Code unknown
Body Length or Diameter 18mm
Body Breadth 6 mm
Output Type Phototransistor
Supply Voltage-Max (Vsup) 1.5V
Termination Type SOLDER
Response Time 30μs, 30μs
Rise Time 30μs
Forward Voltage 1.2V
Max Collector Current 20mA
Sensing Distance 0.178 (4.5mm)
Collector Emitter Breakdown Voltage 30V
Sensing Method Reflective
Current - DC Forward (If) (Max) 50mA
Sensors/Transducers Type LINEAR POSITION SENSOR,PHOTOELECTRIC,DIFFUSE
Output Range 0.05-0.60mA
Measurement Range-Max 5 mm
Dimensions
Body Height 9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
