RoHS
/
Package TO-18-2
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO 890NM TOP VIEW TO18
PDF
/
Inventory: 9279
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Current - Dark (Id) (Max) 100nA
Dark Current 100nA
Wavelength 890nm
Current - Collector (Ic) (Max) 50mA
Voltage - Collector Emitter Breakdown (Max) 30V
Collector Emitter Breakdown Voltage 30V
Max Collector Current 50mA
Collector Emitter Voltage (VCEO) 30V
Power - Max 250mW
Polarity NPN
Orientation Top View
Max Power Dissipation 250mW
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2016
Packaging Bulk
Operating Temperature -40°C~100°C TA
Physical
Package / Case TO-18-2
Mounting Type Through Hole
Mount Through Hole
