OP604TX
RoHS
/
Package Pill
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO TOP VIEW PILL
PDF
/
Inventory: 2844
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Snap in, Surface Mount
Mounting Type Surface Mount
Package / Case Pill
Number of Pins 2
Technical
Operating Temperature -55°C~125°C TA
Packaging Bulk
Published 2010
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Max Power Dissipation 50mW
Orientation Top View
Number of Elements 1
Polarity NPN
Power Dissipation 50mW
Viewing Angle 36°
Power - Max 50mW
Rise Time 20μs
Fall Time (Typ) 20 μs
Collector Emitter Voltage (VCEO) 50V
Max Collector Current 8mA
Collector Emitter Breakdown Voltage 50V
Voltage - Collector Emitter Breakdown (Max) 50V
Current - Collector (Ic) (Max) 8mA
Dark Current 25nA
Current - Dark (Id) (Max) 25nA
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
