RoHS
RoHS compliant
RoHS compliantPackage Pill
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO 890NM TOP VIEW PILL
PDF
/
Buying Options
Total Price: USD $6.53
Unit Price: USD $6.534303
≥1 USD $6.534303
≥200 USD $2.607419
≥400 USD $2.520768
≥800 USD $2.477442
Inventory: 4388
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Snap in, Surface Mount
Mounting Type Surface Mount
Package / Case Pill
Number of Pins 2
Technical
Operating Temperature -65°C~125°C TA
Packaging Bulk
Published 1997
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -65°C
Max Power Dissipation 50mW
Orientation Top View
Number of Elements 1
Polarity NPN
Power Dissipation 50mW
Power - Max 50mW
Rise Time 15μs
Fall Time (Typ) 15 μs
Collector Emitter Voltage (VCEO) 25V
Max Collector Current 50mA
Collector Emitter Breakdown Voltage 25V
Voltage - Collector Emitter Breakdown (Max) 25V
Current - Collector (Ic) (Max) 50mA
Wavelength 890nm
Collector Emitter Saturation Voltage 400mV
Max Breakdown Voltage 25V
Dark Current 100nA
Current - Dark (Id) (Max) 100nA
Compliance
RoHS Status RoHS Compliant
Alternative Model
