RoHS
/
Package 1206 (3216 Metric)
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO 935NM TOP VIEW 1206
PDF
/
Inventory: 7141
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Number of Pins 2
Technical
Operating Temperature -25°C~85°C TA
Packaging Tape & Reel (TR)
Published 2007
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Max Power Dissipation 75mW
Orientation Top View
Case Code (Metric) 3216
Case Code (Imperial) 1206
Operating Supply Voltage 30V
Number of Elements 1
Polarity NPN
Power Dissipation 75mW
Viewing Angle 160 °
Power - Max 75mW
Rise Time 15μs
Fall Time (Typ) 15 μs
Collector Emitter Voltage (VCEO) 30V
Max Collector Current 20mA
Collector Emitter Breakdown Voltage 30V
Power Consumption 75mW
Voltage - Collector Emitter Breakdown (Max) 30V
Current - Collector (Ic) (Max) 20mA
Wavelength 935nm
Collector Emitter Saturation Voltage 400mV
Max Breakdown Voltage 30V
Dark Current 100nA
Current - Dark (Id) (Max) 100nA
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
