PT4810E0000F
RoHS
/
Package Radial
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO 800NM SIDE VIEW RAD
PDF
/
Inventory: 979
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Current - Dark (Id) (Max) 1mA
Dark Current 1mA
Wavelength 800nm
Current - Collector (Ic) (Max) 50mA
Voltage - Collector Emitter Breakdown (Max) 35V
Collector Emitter Breakdown Voltage 35V
Max Collector Current 50mA
Collector Emitter Voltage (VCEO) 35V
Fall Time (Typ) 350 μs
Rise Time 400μs
Power - Max 75mW
Viewing Angle 70°
Output Current 50mA
Orientation Side View
Max Power Dissipation 75mW
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1997
Packaging Tube
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
