PT480F
RoHS
/
Package Radial
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO 860NM SIDE VIEW RAD
PDF
/
Buying Options
Total Price: USD $2.98
Unit Price: USD $2.98395
≥1 USD $2.98395
≥10 USD $2.44815
≥100 USD $2.37215
≥500 USD $2.2952
≥1000 USD $2.2192
Inventory: 1115
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 2.95mm
Length 3mm
Height 21.5mm
Technical
Current - Dark (Id) (Max) 100μA
Dark Current 100μA
Wavelength 860nm
Current - Collector (Ic) (Max) 20mA
Voltage - Collector Emitter Breakdown (Max) 35V
Collector Emitter Breakdown Voltage 35V
Max Collector Current 20mA
Collector Emitter Voltage (VCEO) 6V
Fall Time (Typ) 3.5 μs
Rise Time 3μs
Power - Max 75mW
Viewing Angle 70°
Power Dissipation 75mW
Polarity NPN
Number of Elements 1
Orientation Side View
Max Power Dissipation 75mW
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 1997
Packaging Tube
Operating Temperature -25°C~85°C TA
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
