30-01228
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 28AWG TPU SHLD 2CON 153M
PDF
/
Buying Options
Total Price: USD $92.45
Unit Price: USD $92.4528
≥1 USD $92.4528
≥10 USD $75.64656
≥100 USD $58.8368
Inventory: 44
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Conductor Material Copper, Bare
Jacket (Insulation) Material Thermoplastic Polyurethane (TPU)
Shield Material Copper, Bare
Technical
Operating Temperature -40°C~80°C
Packaging Spool
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Conductors 2
Wire Gauge 28 AWG
Voltage 300V
Cable Type Multi-Conductor
Jacket Color Black
Conductor Strand 19/0.0031
Jacket (Insulation) Diameter 0.150 (3.81mm)
Conductor Insulation Thermoplastic Elastomer (TPE)
Shield Type Braid
Shield Coverage 65%
Dimensions
Length 502.0' 153.0m
Jacket (Insulation) Thickness 0.0315 0.800mm
Compliance
RoHS Status ROHS3 Compliant
Ratings UL Style 20280
