CR3937-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
High Performance Cable 2Conductors 14AWG 4.92mm White 600VAC
PDF
/
Inventory: 9805
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Cable
Conductor Material Copper, Silver Coated
Jacket (Insulation) Material Ethylene Tetrafluoroethylene (ETFE)
Shield Material Copper, Silver Coated
Technical
Operating Temperature 200°C
Published 2015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color White
Number of Conductors 2
Wire Gauge 14 AWG
Voltage 600V
Max Voltage Rating (AC) 600V
Cable Type Multi-Conductor
Jacket Color White
Conductor Strand 19/27
Jacket (Insulation) Diameter 0.194 (4.93mm)
Conductor Insulation Ethylene Tetrafluoroethylene (ETFE)
Wire/Cable Diameter 4.92 mm
Shield Type Braid
Shield Coverage 85%
Dimensions
Jacket (Insulation) Thickness 0.0075 0.191mm
Compliance
RoHS Status RoHS Compliant
