55PC1223-24-2/6-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
55PC CABLE
PDF
/
Inventory: 8050
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Conductor Material Copper, Nickel Coated
Jacket (Insulation) Material Ethylene Tetrafluoroethylene (ETFE)
Shield Material Copper, Nickel Coated
Technical
Operating Temperature 200°C
Published 2007
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Color White
Voltage - Rated 600V
Number of Conductors 2
Wire Gauge 24 AWG
Voltage 600V
Cable Type Multi-Conductor
Wire/Cable Gauge 24 AWG
Jacket Color White
Conductor Strand 19/36
Jacket (Insulation) Diameter 0.109 (2.77mm)
Conductor Insulation Ethylene Tetrafluoroethylene (ETFE)
Wire/Cable Diameter 1 mm
Shield Type Braid
Shield Coverage 85%
Outside Diameter 2.7686 mm
Wire/Cable Color Blue
Dimensions
Jacket (Insulation) Thickness 0.0065 0.165mm
Compliance
RoHS Status RoHS Compliant
