55PC1132-24-MST3-9CS3296
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
55PC CABLE
PDF
/
Buying Options
Total Price: USD $2.37
Unit Price: USD $2.37241
≥1 USD $2.37241
Inventory: 1849
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Conductor Material Copper, Silver Coated
Jacket (Insulation) Material Ethylene Tetrafluoroethylene (ETFE)
Shield Material Copper, Silver Coated
Technical
Operating Temperature 200°C
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Conductors 3
Wire Gauge 24 AWG
Voltage 600V
Cable Type Multi-Conductor
Jacket Color White
Conductor Strand 19/36
Jacket (Insulation) Diameter 0.108 (2.74mm)
Conductor Insulation Ethylene Tetrafluoroethylene (ETFE)
Shield Type Braid
Shield Coverage 85%
Dimensions
Jacket (Insulation) Thickness 0.0070 0.178mm
Compliance
RoHS Status RoHS Compliant
