55PC1131-20-3/6/9-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
55PC CABLE
PDF
/
Inventory: 8097
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Jacket (Insulation) Thickness 0.0075 0.191mm
Technical
Wire/Cable Color White
Outside Diameter 3.53 mm
Shield Coverage 85%
Shield Type Braid
Wire/Cable Diameter 1.2573 mm
Conductor Insulation Ethylene Tetrafluoroethylene (ETFE)
Jacket (Insulation) Diameter 0.139 (3.53mm)
Conductor Strand 19/32
Jacket Color White
Wire/Cable Gauge 20 AWG
Cable Type Multi-Conductor
ELV Compliant
Voltage 600V
Wire Gauge 20 AWG
Number of Conductors 3
Voltage - Rated 600V
Color White
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Operating Temperature 150°C
Physical
Shield Material Copper, Tinned
Jacket (Insulation) Material Ethylene Tetrafluoroethylene (ETFE)
Conductor Material Copper, Tinned
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 10 Weeks
