2214030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 14AWG BLACK FT
PDF
/
Buying Options
Total Price: USD $3.07
Unit Price: USD $3.0712
≥1 USD $3.0712
≥10 USD $2.8512
≥100 USD $2.74208
≥500 USD $2.673942
≥1000 USD $2.61888
≥3000 USD $2.454144
Inventory: 1251
Minimum: 1
-
+
Technical Details
Physical
Insulation Material PVC/NYLON
Conductor Material Copper, Bare
Jacket (Insulation) Material Thermoplastic Polymer
Shield Material Aluminum; Copper, Tinned
Technical
Packaging Digi-Spool?, Continuous Spool
Series ?LFLEX?
Feature Oil Resistant
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 888Ohm
Additional Feature VNTC CABLES
Shielding YES
Construction STRANDED
Number of Conductors 3
Approval Agency CE; CSA; CUL; MSHA; UL
Operating Temperature (Max) 90°C
Operating Temperature (Min) -25°C
Wire Gauge 14 AWG
Connector Support Type WIRE AND CABLE
Cable Type Multi-Conductor
Jacket Color Black
Conductor Strand 50/0.0102
Usage Industrial
Jacket (Insulation) Diameter 0.387 (9.83mm)
Conductor Insulation Poly-Vinyl Chloride (PVC)
Shield Type Foil, Braid
Shield Coverage 100%, 70%
Rated Voltage 600V
Wire and Cable Name FLEXIBLE CORD AND FIXTURE WIRE
Cross Section Area 2.5 mm2
Dimensions
Length Enter Number of Feet in Order Quantity
Compliance
RoHS Status RoHS Compliant
