E2102S.30.86
RoHS
/
Package Aluminum
Category Cables, Wires / Multiple Conductor Cables
Description
Cable;2Cond;22AWG;7x30;BC;PVC ins;Foil;Natural PVC jkt;CMP
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1617
≥1 USD $0.1617
≥10 USD $0.151897
≥100 USD $0.144056
≥500 USD $0.137201
≥1000 USD $0.128383
≥3000 USD $0.127398
Inventory: 1029
Minimum: 1
-
+
Technical Details
Dimensions
Height 215.9mm
Insulation Thickness 381μm
Jacket (Insulation) Thickness 0.0150 0.381mm
Width 330.2mm
Length 1000.0' 304.8m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Poly-Vinyl Chloride (PVC)
Insulation Diameter 3.2512 mm
Jacket (Insulation) Diameter 0.128 (3.25mm)
Usage Alarm, Security, Sound
Conductor Strand 7/30
Jacket Color Natural
Wire/Cable Gauge 22 AWG
Wire/Cable Type Multi-Conductor
Cable Type Multi-Conductor
Voltage 300V
Wire Gauge 22 AWG
Approval Agency UL
Number of Conductors 2
Color Natural
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Drain Wire
Operating Temperature 0°C~75°C
Physical
Shield Material Flexfoil?
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC), Plenum
Conductor Material Copper, Bare
Weight 5.443108kg
Insulation Material PVC
Package / Case Aluminum
Mount Cable
Supply Chain
Factory Lead Time 6 Weeks
Compliance
Lead Free Exempt
RoHS Status Non-RoHS Compliant
