E2022S.41.10
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE RISER SHIELD 2COND 20AWG
PDF
/
Buying Options
Total Price: USD $46.68
Unit Price: USD $46.6752
≥1 USD $46.6752
≥10 USD $38.19024
≥100 USD $29.70352
Inventory: 61
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Cable
Package / Case 100
Insulation Material PVC
Conductor Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Shield Material Flexfoil?
Technical
Operating Temperature -20°C~75°C
Feature Drain Wire
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 75°C
Min Operating Temperature -20°C
Color Grey
Number of Conductors 2
Wire Gauge 20 AWG
Voltage 300V
Cable Type Multi-Conductor
Wire/Cable Type Multi-Conductor
Wire/Cable Gauge 20 AWG
Jacket Color Gray
Conductor Strand 7/28
Usage Alarm, Security, Sound
Jacket (Insulation) Diameter 0.142 (3.61mm)
Insulation Diameter 3.6068 mm
Conductor Insulation Poly-Vinyl Chloride (PVC)
Shield Type Foil
Shield Coverage 100%
Dimensions
Length 1000.0' 304.8m
Jacket (Insulation) Thickness 0.0080 0.203mm
Insulation Thickness 381μm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
