C9030A.41.10
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Cables, Wires / Multiple Conductor Cables
Description
CABLE 3COND 18AWG GRAY 1000
PDF
/
Buying Options
Total Price: USD $184.08
Unit Price: USD $184.0784
≥1 USD $184.0784
≥10 USD $150.61024
Inventory: 81
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Insulation Thickness 812.8μm
Jacket (Insulation) Thickness 0.0320 0.813mm
Length 1000.0' 304.8m
Technical
Conductor Insulation Poly-Vinyl Chloride (PVC)
Insulation Diameter 6.0198 mm
Jacket (Insulation) Diameter 0.237 (6.02mm)
Conductor Strand 16/30
Jacket Color Gray
Wire/Cable Gauge 18 AWG
Wire/Cable Type Multi-Conductor
Cable Type Multi-Conductor
Voltage 300V
Wire Gauge 18 AWG
Approval Agency CSA, UL
Number of Conductors 3
Voltage - Rated DC 300V
Color Grey
Min Operating Temperature -30°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Rip Cord
Series Exzel?
Packaging Spool
Operating Temperature -30°C~105°C
Physical
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Insulation Material PVC
Package / Case 100
Mount Cable
